RAH218

RAH

RAH  is a aero road bike compatible to the TT bike performance. It's a bike for who don't want to limit where and how they ride by getting a tri-specific bike. It comes with full internal cable routing to give the bike more clean aesthetic.

1.Head tube upper and lower both are 1-1/2, with tapered front fork standpipe for precise handling

RAH

2.Fork: Design for AERO, adding the plane of the forks to enhance the rigidity

RAH

3.Top tube: Smooth Top Tube shape degisn for AERO

RAH

4. Seat tube: aero seat tube design, concealed seat clamp, reducing wind resistance and being clean and beautiful

RAH

5.BB86: Carbon BB86 is more lighter, this gives a wider bottom bracket shell and allows to build a more broadly-spaced chainstays as well as enhance the frame stiffness

RAH

6. 12 x 142 mm axle standard is to make thru-axles as quick and easy to use as a quick release system

RAH

7.All cables are internally routed to give the bike a clean aesthetic and to keep cables protected from the elemants

RAH
  • RAH

  • RAH

  • RAH

  • RAH

  • RAH

  • RAH

  • RAH

SPECIFICHE TECNICHE



Size5052545658
ASeat Tube Length500520540560580
BTop Tube Length528541553567580
CHead Tube Length118136148166184
DHead Tube Angle71.2°71.4°72.7°72.9°73.2°
ESeat Tube Angle74°73.7°73.4°73.1°72.8°
FBottom Bracket Drop7070707070
GChainstay Length398398400400400
HFront Center576583588596604
IOffset4545454545
JWheel Base970978984986996
KStack514532550568586
LReach379384389394399
MFork Length368368368368368
